PTO Driven Truck Mounted Concrete Line Pump AI-50CLPP 40M³/H For Australia

Product Categories

Achieve Innovations (Changsha) Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: PTO Driven Truck Mounted Concrete Line Pump AI50CLPP 40MH For Australia
Brand: ACHIEVE
Price: 29 USD

Add to Cart

Truck Mounted Concrete Line Pump PTO Driven AI-50CLPP For Australia

Items			Model
Items			AI-50CLPP
Pumping System	Max. Pumping Volumn	m3/h	50
	Max. Pumping Pressure	MPa	10
	Pumping Frequency	min-1	24.3
	Swing Type		S Tube
	Hydraulic Oil Cylinder Diameter * Stroke	mm	DN 100 * 1200
	Concrete Cylinder Diameter * Stroke	mm	DN 180 * 1200
	Hopper Capacity * Feeding Height	L * mm	500 * 1400
	Output Diameter	mm	DN 180
	Max. Aggeateer Diameter	mm	40
	Slump	cm	12~23
Upper-	Weight	kg	4900
structure	Dimension(Length×Width×Height)	mm	7515×2300×2589
Hydraulic System	Hydraulic System Type		Open loop
	Hydraulic System Pressure	MPa	32
	Hydraulic Oil Tank	L	280
	Hydraulic Oil Cooling Type		Air Cool
	Cleaning Type		Water + Air Wash
	Water Tank	L	500
Others	Lubrication System		Auto-lubirication
	Control Sytem		Manual Control Box
	Control Sytem		+HBC Raido Remote Control
