Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System
End Hose
• Compact in design, 47m pump mounted on a 3-axle truck.
• Boom intelligent damping technology:The soft control of booms in
starting, slewing and stopping reduces the impacting vibration of
booms and therefore makes the vehicle operate more stably,
reliably and safely.
• Accurate pumping control technology(APC):Great leap of pumping
accuracy and adaptability, improving pump efficiency.
• Adaptive concrete material pumping technology: Improve pumping
control system for poor concrete with segregation and big
viscosity, and auto-adaptive pumping mode, reducing the block rate
by more than 50%.
Main Parameters
| Model | ZLJ5339THB 47X-5RZ |
| Pumping system | Max. Theor. output | m3/h | 170/120 |
| Max. Theor. concrete output Pressure | MPa | 8.3/12 |
| Rated working pressure | MPa | 35 |
| Pumping frequency | min-1 | 25/18.5 |
| Hopper capacity | L | 600 |
| Filling height | | 1540 |
| Hydraulic system type | | Open loop |
| Distribution valve | | S valve |
| Oil cylinder dia.×stroke | mm | Φ150×2100 |
| Concrete cylinder dia.×stroke | mm | Φ260×2100 |
| Hydraulic oil cooling | | Air cooling |
| Recommended concrete slump | cm | 12~23 |
| Max. aggregate dimension | mm | 40 |
| Placing boom | Structure type | | 47X-5RZ |
| Placing depth | m | 47 |
| Horizontal distance | m | 42.7 |
| Placing depth | m | 33.4 |
| Slewing angle | | ±270° |
| Boom number | | 5 |
| The length of boom section | mm | 9380/8130/7930/8610/8950 |
| Sections folding angle | | 90°/180°/180°/240°/180° |
| Pipe diameter | mm | 125 |
| End hose length | mm | 3000 |
| Min. height of opening placing boom | mm | 9700 |
| Outriggers span (front×rear×side) | mm | 9310×9675×9420 |
| Chassis and the whole machine | Chassis model | | ACTROS 3341 6×4 |
| Wheelbase | mm | 4500+1350 |
| Engine type | | OM501LA |
| Engine power | kW/(r/min) | 300/1800 |
| Engine moment | N.m/(r/min) | 2000/1080 |
| Maximum displacement | cc | 11946 |
| Oil tank cubage | L | 400 |
| Tail gas exhaust standard | | 欧Ⅳ |
| Total weight | kg | 34000 |
| Overall dimensions | mm | 12020×2500×4000 |
| Others | Lubrication mode | | Automatic lubrication |
| Oil tank volume | L | 780 |
| Control mode | | Manual+remote control |
| Maximum water pressure | MPa | 7 |
| Water tank volume | L | 400 |
| Pipe cleaning mode | | Water cleaning/dry cleaning |
Achieve is located in Changsha, China,
The same city as ZOOMLION & SANY.
We supply TOP QUALITY refurbished concrete pumps to our customers overseas.
Brand: ZOOMLION, Putzmeister, SANY, XCMG, JUNJIN etc.
Refurbishing quality is our first concern.Achieve Innovations (Changsha) Co.,Ltd.
♥. A leading Supplier in the Concrete Machinery Industry for Premium
quality China-made Products
♥. Specializing in Concrete Machinery, Used Concrete Pumps, Concrete
Batching Plants, Mortar Pump, Tailor-made Equipment & Parts
♥. We are a professional team, with more than 15 years of experience
in this industry.
Q1:Are you a manufacture or a trading company?
A1:We are a trading company since 2018 year.
Q2:What is your advantage? - More than a decade,We have been focusing on concrete pump since.
A2:-Professionally and Highly remanufactured standard for used
concrete pump machines
-Providing competitive price for customer.
-Professional sales service availably.
Q3:What is your main products?
A3:Truck-mounted concrete pump, Concrete pump truck , Concrete line
pump ,Concrete mixer truck, and Concrete pump spare parts, Crane
and Lubricate oil .we have the whole series products you need.
Q4:What kind terms of payment can be accepted? A4:Normally we can work on T/T term or L/C term.
Q5:What about the delivery time?
A5:7-30 days after receving the deposit.
Q6:What about the warranty time?
A6:12 months after shipment or 2000 working hours.
Q7:What about the Minimum Order Quantity?
A7:The MOQ is 1 pcs.
